- These precision calibration machines in the series have been designed to calibrate stone slabs, tiles, and mosaics with ease. They feature dual cooling water channels, both internal and external, which work together to slowly heat the blade and rapidly cool it, while also increasing water volume for faster blade heat dissipation.
- The machine is equipped with a user-friendly PLC touch screen, allowing for electric lifting and lowering adjustments while providing real-time monitoring of the tool head's lifting and lowering numbers. This results in precise control over the size of the tool head's movements with exceptional accuracy. Additionally, the main motor is protected with advanced PLC current detection technology, ensuring constant monitoring of the current to provide accurate and immediate response times.
|
Description |
LXF-2T |
Unit |
|
Calibrating heads no. |
2 |
pcs |
|
Available working width |
300-1250（可选） |
mm |
|
Available working thickness |
10-50 |
mm |
|
Water consumption |
150 |
m³/h |
|
Main Motor Power |
30 |
kw |
|
Overall Dimension |
4500x2300x2200 |
mm |
|
Gross weight |
6500 |
kgs |
English Foundation Drawing, Electric Drawing, English Manual
Electric control cabinet
Dual Internal and external water channels
Spindle
Specialized bearing seat
Dust removal device
PLC Control
Q: May we pay a visit to your factory?
A: Certainly, we would be happy to have you at our factory. Just let us know ahead of time and we'll arrange for transportation. Don't hesitate to contact us if you require any assistance.
Q: Do you provide OEM services? Can you manufacture products based on our specifications?
A: Absolutely, we offer OEM services and can customize products to meet your requirements using our existing structures.
Q: What is the ideal container for one automatic granite stone slab calibrating machine?
A: A 20-foot container is sufficient for transporting one set of the automatic stone slab calibrating machine.
